Snowkey 10000kg/24hr Plate Ice Maker Machine - P100W
Description
Description
Snowkey 10,000kg/24hr Plate Ice Machine (P100W)
A large-capacity industrial plate ice machine producing up to 10,000kg of plate ice per day. Plate ice is thick, hard and slow-melting, making it ideal where ice needs to hold temperature for longer.
Please enquire if you require a larger plate ice plant.
Applications
- Fishing and seafood processing
- Meat and poultry processing
- Food processing
- Supermarkets and cold-chain logistics
- Chemical and dye processing
- Medical research and cold storage projects
Features
- Stainless steel plate evaporator with two freezing surfaces for full production
- Adjustable ice thickness from 3mm to 20mm
- Flow-type plate design for higher refrigeration efficiency and lower energy use
- Refrigerant hot-gas harvest – fast and free of secondary contamination
- Open evaporator – plates, water spray and channels are easy to clean
- Stainless steel ice-contact parts meeting HACCP requirements
- Simple structure with few moving parts for easy maintenance
- Hot-dip galvanised welded steel frame for corrosion resistance and long service life
- Fully automatic control
Specifications
| Model | P100W |
| Ice output | 10,000kg / 24hr |
| Ice thickness | 3–20mm (adjustable) |
| Ice output dimension | 1400 x 130mm |
| Compressor | SP-4HF3000 (2 sets), 60HP total |
| Compressor refrigeration capacity | 65kW |
| COP | 2.32kW/kW |
| Running power consumption | 34.2kW |
| Installed power | 51.2kW |
| Energy use | 78.14kWh per tonne of ice |
| Water consumption | 420.83L/hr |
| Refrigerant | R404A / R507A |
| Condensing / evaporating temp. | 38°C / -18°C |
| Overall dimensions | L3170 x W2200 x H2450mm |
| Weight | 4,300kg |
Operating conditions
- Rated at water supply temperature 20°C and ambient temperature 33°C
- Operating range: water temperature 0–35°C, ambient temperature 5–40°C
Price on application – please contact us for pricing, installation and lead times: 09 945 9257 or info@icetec.co.nz
Specifications may change due to ongoing product development. Please contact us to confirm details for your application.
